FUEL SYSTEM (DFI) 3-7
Exploded View

                                                          Torque
No.                        Fastener                                        Remarks
                                                 N·m       kgf·m   ft·lb
 1    Fuel Pump Assembly Screws                  0.98       0.10 8.7 in·lb    R
 2    Fuel Pump Bolts                             10         1.0 89 in·lb    L, S
  3. CA Model
  4. Other than CA Model
  L: Apply a non-permanent locking agent.
  R: Replacement Parts
  S: Follow the specified tightening sequence.
