FUEL SYSTEM (DFI) 3-9
DFI System
  1. ECU
  2. Battery
  3. IMU
  4. Front Wheel Rotation Sensor
  5. Rear Wheel Rotation Sensor
  6. ABS Hydraulic Unit
  7. Accelerator Position Sensor
  8. ETV Actuator
  9. Throttle Position Sensor
 10. Vehicle-down Sensor
 11. Pressure Regulator
 12. Fuel Pump
 13. Fuel Filter
 14. Gear Position Sensor
 15. Stick Coils
 16. Oxygen Sensor
 17. Intake Air Temperature Sensor
 18. Delivery Pipe Assy
 19. Fuel Injectors
 20. Water Temperature Sensor
 21. Crankshaft Sensor
 22. Purge Valve (Other than CA Model)
 23. Intake Air Pressure Sensor #1
 24. Intake Air Pressure Sensor #2
 25. Air Switching Valve
 26. Air Flow
 27. Fuel Flow
