ELECTRICAL SYSTEM 16-5
Exploded View

                                                      Torque
No.                      Fastener                                          Remarks
                                               N·m     kgf·m     ft·lb
 1     Turn Signal Light Mounting Screws       1.2      0.12   11 in·lb
 2     Switch Housing Bolts                    3.5      0.36   31 in·lb
 3     Front Brake Light Switch Screw          0.3      0.03   2.7 in·lb      L
     4. CA Model
     L: Apply a non-permanent locking agent.
