APPENDIX 18-17
Cable, Wire, and Hose Routing
  1. Clamps (Hold the main harness, and install the clamps to the frame as shown.)
  2. Main Harness
  3. Intake Air Pressure Sensor
  4. Radiator Fan Motor Lead
  5. Front Wheel Rotation Sensor Lead
  6. Air Switching Valve Lead Connector
  7. ETV Actuator Lead Connector
  8. Side Stand Switch Connector
  9. Clamp (Hold the side stand switch lead.)
 10. Clamp (Hold the main harness at the gray tape position, and install it to the bracket as shown.)
 11. Stick Coil #1 Lead Connector
 12. Stick Coil #2 Lead Connector
 13. Stick Coil #3 Lead Connector
 14. Clamp (Hold the main harness to the bracket.)
 15. Stick Coil #4 Lead Connector
