APPENDIX 18-47
Cable, Wire, and Hose Routing
  1. Water Temperature Sensor
  2. Alternator Lead
  3. Engine Subharness
  4. Engine Ground Cable
  5. Clamp (Hold the engine subharness as shown.)
  6. Clamp (Hold the alternator lead as shown.)
  7. Gear Position Sensor
  8. Run the oil pressure switch lead to the inside of the water hose.
  9. Cover the oil pressure switch with the switch cover.
 10. Water Pipe
 11. Viewed from A
 12. Viewed from B
