APPENDIX 18-53
Cable, Wire, and Hose Routing
  1. Front Brake Hose (to Front Master Cylinder)
  2. Clamp (Hold the front brake hose (to front master cylinder).)
  3. Front Brake Hose (to Front Caliper)
  4. Front Wheel Rotation Sensor Lead
  5. Clamps (Hold the front brake hose (to front caliper) and front wheel rotation sensor lead at the
     white painted mark of the front wheel rotation sensor lead.)
  6. Clamp (Hold the front wheel rotation sensor lead.)
  7. Clamps (Hold the front brake hose (to front caliper).)
  8. Front Wheel Rotation Sensor
  9. Clamps (Hold the front brake pipes.)
 10. Clamp (Hold the front brake pipe (to front master cylinder).)
 11. About 15°
 12. About 90°
