APPENDIX 17-5
Cable, Wire, and Hose Routing
  1. Clamp (Hold the throttle cable (decelerator), throttle cable (accelerator) and right switch housing
     lead, and face the locking portion of the clamp to the upside.
  2. Right Switch Housing Lead
  3. Front Brake Hose (to Front Master Cylinder)
  4. Meter Lead
  5. Clutch Cable
  6. Clamp (Hold the left switch housing lead, and face the locking portion of the clamp to the upside.)
  7. Left Switch Housing Lead
  8. Clamp (Run the clutch cable and left switch housing lead in order from the outside of the mo-
     torcycle.)
  9. Front Wheel Rotation Sensor Lead
 10. Throttle Cable (Accelerator)
 11. Throttle Cable (Decelerator)
 12. Clamp (Run the front brake hose (to front master cylinder), throttle cable (decelerator), throttle
     cable (accelerator) and right switch housing lead in order from the outside of the motorcycle.)
