APPENDIX 17-9
Cable, Wire, and Hose Routing
  1. Main Harness
  2. Clamp (Hold the main harness, and install the clamp to the bracket.)
  3. Cover the right switch housing lead connector, ignition switch lead connector, radiator fan motor
     lead connector, immobilizer antenna lead connector (equipped models) and left switch housing
     lead connector with the dust cover.
  4. Clamp (Hold the right switch housing lead, ignition switch lead, radiator fan motor lead, immobi-
     lizer antenna lead (equipped models) and left switch housing lead, and face the locking portion
     of the clamp to the upside.
