FUEL SYSTEM (DFI) 3-15
DFI System
Part Names
   1. ECU
   2. Rear Wheel Rotation Sensor
   3. Immobilizer (Equipped Models)/Kawasaki Diagnostic System Connector
   4. Fuel Pump
   5. ABS Hydraulic Unit
   6. Frame Ground 4
   7. Frame Ground 3
   8. Frame Ground 2
   9. Engine Ground
 10. Battery 12 V 8 Ah
  11. Main Fuse 30 A
 12. Starter Relay
 13. ECU Fuse 15 A
 14. Relay Box
 15. Fuel Pump Relay
 16. ECU Main Relay
 17. Radiator Fan Relay
 18. Frame Ground 9
 19. Frame Ground 6
 20. Meter Unit
 21. Fuse Box 1
 22. Fan Fuse 15 A
 23. Ignition Fuse 15 A
 24. Immobilizer Antenna (Equipped Models)
 25. Immobilizer Amplifier (Equipped Models)
 26. Ignition Switch
 27. Front Wheel Rotation Sensor
 28. Engine Stop Switch
 29. Starter Button
 30. Fan Motor
 31. Air Switching Valve
 32. Spark Plugs
 33. Stick Coil #1, #2, #3, #4
 34. Purge Valve (Other than US, CA, ID and SEA-B2 Models)
 35. Crankshaft Sensor
 36. Fuel Injector #1
 37. Fuel Injector #2
 38. Fuel Injector #3
 39. Fuel Injector #4
 40. Subthrottle Valve Actuator
 41. Main Throttle Sensor
 42. Subthrottle Sensor
 43. Intake Air Pressure Sensor #2
 44. Intake Air Pressure Sensor #1
 45. Vehicle-down Sensor
 46. Intake Air Temperature Sensor
 47. Water Temperature Sensor
 48. Oxygen Sensor
○Color Codes:
    BK: Black           GY: Gray          PU: Purple
    BL: Blue            LB: Light Blue     R: Red
    BR: Brown           LG: Light Green    V: Violet
    CH: Chocolate        O: Orange         W: White
    DG: Dark Green       P: Pink           Y: Yellow
     G: Green
